Get started with Open Source Code Quality Management Platform - Sonar in few minutes

by user

Sonar is an open source platform for code quality management. It covers different aspects of code quality management like code duplication, complexity, coverage by unit tests, architecture & design, rule based defect identification etc. This post will help you to get started with Sonar in few minutes.

Tools and Technologies used in this article

  1. Sonar 3.5.1

1. Download and Install Sonar

Download Sonar 3.5.1 and extract the same in your local directory.
Note: Name of the folder / directory where you have unzipped Sonar should not start with digit.

2. Start Sonar Server

Open the terminal and execute the command 'bin/macosx-universal-64/sonar.sh console'.

Terminal

static-108:~ abhimun$ /Users/srccodes/sonar-3.5.1/bin/macosx-universal-64/sonar.sh console
Running sonar...
wrapper  | --> Wrapper Started as Console
wrapper  | Launching a JVM...
jvm 1    | Wrapper (Version 3.2.3) http://wrapper.tanukisoftware.org
jvm 1    |   Copyright 1999-2006 Tanuki Software, Inc.  All Rights Reserved.
jvm 1    |
jvm 1    | 2013-05-12 23:39:23.328:INFO::Logging to org.sonar.application.FilteredLogger@314c194d via org.sonar.application.FilteredLogger
jvm 1    | 2013-05-12 23:39:23.364:INFO::jetty-6.1.25
jvm 1    | 2013-05-12 23:39:23.501:INFO::NO JSP Support for /, did not find org.apache.jasper.servlet.JspServlet
jvm 1    | JRuby limited openssl loaded. http://jruby.org/openssl
jvm 1    | gem install jruby-openssl for full support.
jvm 1    | 2013-05-12 23:39:44.160:INFO::Started SelectChannelConnector@0.0.0.0:9000

Note:
Sonar provides different scripts for different operating systems. Based on your OS execute the corresponding script available inside 'bin' folder. For example, if you have Windows-X86 32 bit machine, then execute '/bin/windows-x86-32/StartSonar.bat' to start Sonar.

Once started, Sonar application will be available on http://localhost:9000. Sonar by default runs on Jetty Webserver and uses embedded database H2.

3. Configure

Edit '/conf/sonar.properties' to configure host/port, context path, database based on your requirement.

sonar.properties

# Listen host/port and context path (for example / or /sonar). Default values are 0.0.0.0:9000/.
#sonar.web.host:                           0.0.0.0
#sonar.web.port:                           9000
#sonar.web.context:                        /

Note:
It is recommended to use other database like Oracle, MySQL, SQLServer etc for production environment. In this post, we have used default embedded database H2 for testing purpose only.

4. Browse Sonar Application

Browse to http://localhost:9000 for Sonar exploring administrative features. Use admin/admin as Login/Password to login to the application as administrator.
